bent steering stop (sbk)

Started by 1KDS, August 13, 2010, 03:27:46 PM

Previous topic - Next topic
Print
Go Down Pages1
User actions

1KDS

August 13, 2010, 03:27:46 PM
Getting ready to send this frame off for powder, need advise on how to fix/straighten the stop if it's possible and worth it.


Every bike I've ever owned.

1KDS

#1
August 17, 2010, 04:32:54 PM
No one has any ideas?
The stop looks like a cast piece so I fear it will snap if coaxed back into the original shape
Every bike I've ever owned.

ducpainter

#2
August 17, 2010, 04:42:03 PM
I'd leave it alone for just that reason.

Can you adjust things so the bars don't hit anything?
"Once you accept that a child on the autistic spectrum experiences the world in
 a completely different way than you, you will be open to understand how that
 perspective
    is even more amazing than yours."
    To realize the value of nine  months:
    Ask a mother who gave birth to a stillborn.
"Don't piss off old people The older we get, the less 'Life in Prison' is a deterrent."


1KDS

#3
August 17, 2010, 05:11:29 PM
I'll check, it's in mock up stage at the moment
Every bike I've ever owned.

1KDS

#4
August 17, 2010, 06:02:46 PM
Went out and looked at it.  Maybe a new problem, the stops on the triple aren't contacting the stop on the steering head right, it is the adjustable headstock in the rear setting looks like it would have to be in the forward setting for the stops to properly hit the stop on the tube.  DP, you have a 916 series right? You leave your eccentric in the rear position?  It is a lower off a 1098 and it's a 748 frame but the part numbers on the triples are the same, even though the stops are adjustable on the 1098 lower unit and not on the 748.  When moving to full lock left the stop on the triple hits the pinch bolt area before hitting the stop on the frame and full right the mass of the stop on the triple hits and the adjustment screw doesn't at all.


Every bike I've ever owned.

ducpainter

#5
August 18, 2010, 01:45:47 AM
While not ideal, it looks like the screws can be adjusted to hit.

I wouldn't worry.
"Once you accept that a child on the autistic spectrum experiences the world in
 a completely different way than you, you will be open to understand how that
 perspective
    is even more amazing than yours."
    To realize the value of nine  months:
    Ask a mother who gave birth to a stillborn.
"Don't piss off old people The older we get, the less 'Life in Prison' is a deterrent."


64duc

#6
August 18, 2010, 01:29:14 PM
 From the pics it looks like if you put a nut on the inside of the screw the stop would hit the nut. If you have room you could double nut them and then have adjustment.
94 M900, 64 Diana 250

1KDS

#7
August 18, 2010, 03:21:11 PM
Yeah it's possible.  I'm going to try to mount the 748 lower I have (with slightly different stops) and see how they hit.
Every bike I've ever owned.

ducpainter

#8
August 18, 2010, 03:23:48 PM
Quote from: 1KDS on August 18, 2010, 03:21:11 PM
Yeah it's possible.  I'm going to try to mount the 748 lower I have (with slightly different stops) and see how they hit.
I just think that because of the slight bend the one stop isn't long enough.

Adjust that thing in a little. ;)
"Once you accept that a child on the autistic spectrum experiences the world in
 a completely different way than you, you will be open to understand how that
 perspective
    is even more amazing than yours."
    To realize the value of nine  months:
    Ask a mother who gave birth to a stillborn.
"Don't piss off old people The older we get, the less 'Life in Prison' is a deterrent."


1KDS

#9
August 19, 2010, 07:37:56 AM
The screws aren't hitting at all, it's like they are too far to the rear on both sides, doesn't look like they would hit regardless of how they are adjusted. I'm wondering how the are supposed to work on an eccentric headstock in both the frward and rear settings.
Every bike I've ever owned.

DarkStaR

#10
August 19, 2010, 08:36:21 AM
If it were me, I'd just cut it off, and make one that would work at all head angles and have it welded on before coating.  Seems simple enough.
